PRODUCT SPECIFICATIONS
Item Description
Gauge Size 2” Diameter
Gauge Scale 0,-.30 in/Hg (0<->76 cm/Hg) Vacuum
Accessories 1/4” I.D. X 23” Long Vacuum Hoses (Qty. 2)
1/4” I.D. X 3” Long Vacuum Hoses (Qty. 4)
Tapered Hose Adapters (Qty. 4)
”T” Hose Connector
Straight Hose Connector
Brake Bleeder Valve Adapters (Qty. 2)
Universal Cup Adapter
4 oz. Reservoir Jar
Jar Lids (Qty. 2)
Net Weight 1.8 Lbs
When unpacking, check to make sure all the parts shown on the parts list on pg. are in-
cluded.
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram. Keep
your invoice with this manual. Write the invoice number on the inside of the front cover.
Keep this manual and invoice in a safe and dry place for future reference.
Keep bystanders, children, and visitors away while operating the Brake Bleeder/Vacuum
Pump. Distractions can cause you to lose control. Protect others in the work area from
injury. Provide barriers or shields as needed.
PERSONAL SAFETY
1. Stay alert. Watch what you are doing, and use common sense when operating the Brake
Bleeder/Vacuum Pump. Do not use the tool while tired or under the influence of drugs,
alcohol, or medication. A moment of inattention while operating the tool may result in
serious personal injury.
2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair,
clothing, and jewelry away from moving parts. Loose clothes, jewelry, or long hair can be
caught in moving parts.
3. Do not overreach. Keep proper footing and balance at all times. Proper footing and
balance enables better control of the power tool in unexpected situations.
4. Use safety equipment. Always wear ANSI approved safety glasses underneath a full
face safety shield. Nonskid safety shoes, hard hat, or hearing protection must be used for
appropriate conditions.
UNPACKING
SAVE THIS MANUAL
GENERAL SAFETY RULES
PERSONAL SAFETY
2
Item Description
1. Do not force the tool. Use the correct tool for your application. The correct tool will do the
job better and safer at the rate for which it is designed.
2. Store idle tools out of reach of children and other untrained persons. Tools are dangerous
in the hands of untrained users.
3. Maintain tools with care. Keep tools dry and clean. Properly maintained tools are less
likely to bind and are easier to control. Do not use a damaged tool. Tag damaged tools “Do
not use” until repaired.
4. Check for misalignment or binding of moving parts, breakage of parts, and any other
condition that may affect the tool’s operation. If damaged, have the tool serviced before
using. Many accidents are caused by poorly maintained tools.
5. Use only accessories that are recommended by the manufacturer for your model. Acces-
sories that may be suitable for one tool may become hazardous when used on another tool.
Tool service must be performed only by qualified repair personnel. Service or maintenance
performed by unqualified personnel could result in a risk of injury.
When servicing a tool, use only identical replacement parts. Follow instructions in the
“Inspection, Maintenance, And Cleaning” section of this manual. Use of unauthorized parts
or failure to follow maintenance instructions may create a risk of injury.
SPECIFIC SAFETY RULES
1. Maintain a safe working environment. Keep the work area well lit. Make sure there is
adequate surrounding workspace. Always keep the work area free of obstructions, grease,
oil, trash, and other debris. Do not use the Brake Bleeder/Vacuum Pump in areas near
flammable chemicals, dusts, and vapors. Do not use this product in a damp or wet location.
2. Maintain labels and nameplates on this product. These carry important information. If
unreadable or missing, contact Harbor Freight Tools for a replacement.
3. Keep the Handles of the Brake Bleeder dry, clean, and free from brake fluid, oil, and
grease.
4. Prior to using the Brake Bleeder/Vacuum Pump make sure to read and understand all
warnings, safety precautions, and instructions as outlined in the vehicle manufacturer’s
instruction manual. Every vehicle has specific measurement values for vacuum related
readings. It is beyond the scope of this manual to properly describe the correct procedure
and test data for each vehicle.
5. WARNING! Carbon monoxide is produced while a vehicle’s engine is operating and is
deadly in a closed environment. Early signs of carbon monoxide poisoning resemble the
flu, with headaches, dizziness, or nausea. If you have these signs, the work area may not
be vented properly. Get fresh air immediately.
6. Prior to using the Brake Bleeder/Vacuum Pump, make sure to place the vehicle’s trans-
mission in “PARK” (if automatic) or “NEUTRAL” (if manual). Then, block the tires with chocks.
TOOL USE AND CARE
SERVICE
SPECIFIC SAFETY RULES
3
