Performance PL 155GG-A1 - Page 2

8
7
B
D
Lie Bookcase on its Back.
Attach L-Bracket(7) to
Bottom Panel(F) and Kick
Plate(D) as shown. Tighten
Screws(8) securely.
Insert Shelf Support Pins(6)
into the pre drilled holes and
place Adjustable Shelves(G)
at convenient distances.
6
Screw Adjustable Glide(4)
into bottom of Left Gable(B)
and Right Gable(C).
Attach Right Gable(C) to
Back Panel(A), Top Panel(E),
Bottom Panel(F) and Kick
Plate(D).
6
D
F
7
4
G
Attach Housing Cap(3) to all
Klix Cams(2) by pushing neck
thought center of cam.
8
3
Place Adj. Shelf(G) in center
of bookcase. Fastens with
Center Shelf Locking Pins (5).
F
Attach Top Panel(E) to Left
Gable(B) and Back Panel(A).
AA
Attach Back Panel(A) to Left
Gable(B).
A
4
E
B
5
C
F
B
1 2
B
Attach Kick Plate(D) and
Bottom Panel(F) to Left
Gable(B).
G
F
D
5 SHELF BOOKCASE
3
E
A
E
PL 155GG-A1
5 SHELF BOOKCASE
PL 155GG-A1
PAGE 2 OF 2
