Performax M27BC5 User Manual

CAUTION:
Two people are recommended for assembly.
A
B
BB
Attaching the casters
□ Be sure the drawers are locked and lay the cabinet (A)
□ Attach the swivel casters with brake (D) on the front of the
unit inserting four bolts (AA) per caster into the cabinet (A).
□ Tighten with supplied hex key (CC).
□ Attach the swivel casters without brake (C) on the back of
the unit inserting four bolts (AA) per caster into the
cabinet (A).
□ Return the cabinet (A) to its upright position.
CAUTION: Do not over tighten the bolts.
1
AA
D
A
Attaching the
2
bumpers
□ Position the bumpers (B) over the corner holes. Insert 2
bolts (BB) into bumper holes and tighten with supplied Hex
key (CC). Do not over tighten.
Assembly
5
back
