89
140
Ø8
Ø20
2 4Ø
Ø4
Ø5
min 1875 max 5000
225018x125= 8757X125=
6624
261
Consists of
1 pc 112865 Locking Pin Ø25x180mm coat
1 pc 022230 Cotter Pin 5/1 ga
1 pc 107297 Screw ISO4014-M12x140-8.8-ga
1 pc 710330 Hex-Nut ISO4032-M12-8-ga
Notes
Follow Instructions for Use.
Permissible load-bearing capacity 9t.
For moving climbing units.
Art no. Weight [kg]
127320 158.000 Lifting Beam 9t
Art no. Weight [kg]
022230 0.033 Cotter Pin 5/1 ga
Art no. Weight [kg]
018060 0.014 Cotter Pin 4/1 ga
Accessory (not included)
018060 0.014 Cotter Pin 4/1 ga
For different connections.
Art no. Weight [kg]
105400 0.330 Pin Ø20x140mm ga
Accessories general ACS
