Illustration 27 g01425443
(1) Coolant temperature sensor
(2) Intake manifold pressure sensor
(3) Inlet air temperature sensor
(4) Fuel pressure sensor
(5) Electronic control module
(6) Primary position sensor
(7) Secondary position sensor
(8) Engine oil pressure sensor
Illustration 28 shows the sensors and the ECM in
position on the engine.
SEBU8172-04
33
Operation Section
Sensors and Electrical Components
