Perkins D6500 - Hydraulic Cylinder Parts Guide

Perkins Manufacturing Company 800-882-5292
Creators of the TuckAway® Cart Lifter
www.perkinsmfg.com
Revised: 5/7/2019
Page 35
Parts List Cont.
Item
#
Description
Qty
McNeilus PN
Perkins PN
35
ELBOW 90 6MT-6FT
1
1591641
D63106
36
ADAPTER #6MO-#6FT
1
1591642
D63597
37
ADPT-STR,PERKINS
1
0127779
D63430
38
STUD,FULL .50-13X1.75 ZC
6
1137201
D72001
39
NUT,HEX,LKNY .50-13 G8 ZY
6
1241098
D62081
40
SPACER
2
1591682
D79337
41
SELF-LUB BEARIN 1" DIA C 3/4"
4
NPN
D72179
42
BRG,1.00 IDX .50 LNG,PERKINS
2
1251369
D72108
43
BUSH 1X1 SELF-LUB FIBR GLIDE
2
1591647
D72133
44
BEARING 3/8 X 3/8 SELF-LUBE
2
1591645
D72130
45
HOOK,UPR,PLASTIC (A)
1
1329377
D65255P
45
HOOK,UPR,STEEL (B)
1
0127852
D75014
46
WASH,SPR,SPT .38X.68X.09 ZC
2
0621024
D62106
47
1/4-20 NYLOCK LOCKNUT
2
NPN
D62457
48
BOLT FHCS 3/8-16 X 1 1/4
2
NPN
D62413
49
SCR,FLT,SOC .38-16X1.00 835 ZC (A - ONLY)
4
1108231
D62044
*PN 1591632 COMES WITH (A) OPTIONS.
**PN 1604670 COMES WITH (B) OPTIONS.
***ONLY PN 1591632 COMES WITH ITEMS 30 -
37 FOR HYDRAULIC FITTINGS.
****PN 1604670 COMES WITH ORIFICE
FITTINGS.
*PN 1137212 AND ITEMS 28 & 29 NOT SHOWN.
