Note:
Move TV to center.
7. Secure the Monitor to Monitor Plate
!
!
Caution:
Ensure bolts are
secured firmly.
Warning:
Lift the TV may
require two people
02
09
Hang the monitor to monitor plate [02]
Fasten the bolts [C2] via safty locks [D2] to secure the monitor to monitor
plate [02]
D2
C2
01 02 03 04 05 06 07 08 09 10 11 12
13 14 15 16 17 18 19 20 21 22 23 24
25 26 27 28 29 30 31 32 33 34 35 36
37 38 39 40 41 42 43 44 45 46 47 48
49 50 51 52 53 54 55 56 57 58 59 60
To Next Page
