Caution:
Ensure bolts are
secured firmly.
8.Install the Camera Tray to the Height Adjustable Post
04
02
Secure the camera tray [13] to the top of camera bracket [04] using the
bolt [G2]
Remove the preassembled bolts and washers from the
connecting plate [05]. Then fasten the preassembled bolts
and washers to secure the camera bracket assembly to the height
adjustable post
8-1
8-2
04
13
G2
