2. Connect Post Assembly to Base
Note:
Make sure cables management
windows are facing the rear of base.
Caution:
Ensure bolts are
secured firmly.
01
03
06
Fasten the four bolts [A2] using wrench [F2] to secure the height adjustable post
[03] to base [01]
Slide the decorative cover [06] to the base assembly
Front Side
Back Side
F2
A2
A2
