5. Secure the Monitor Plate to Height Adjustable Post
Secure the monitor plate [02] to height
adjustable post [03] by tightening the
bolts [B2] via connecting plate [05]
6. Secure the Monitor Bracekts to Monitor
Only one bolt size fits your TV.
M6
M4
M8
Too Short Too Long
6-1
1500m
m
1450mm
1400mm
!
Caution:
Ensure bolts are
secured firmly.
02
05
03
B2
F2
