PERLESSMITH PSXFK1 - Attach Wall Plate to Wall; Solid Concrete or Block Option

P4
03
03
M-A M-D
M-H
M-B
M-C
M-E
M-F
M-H
M-G M-I
M-G M-I
Use spacers (M-G, M-I) to
increase extra space for inserting
cables
(a) Flat Back
(b) Round Back / Extra Space
STEP 2A Solid Concrete or Concrete Block Option
STEP 2 Attach Wall Plate to Wall
Avoid potential personal injury or property damage! All lag bolts [A] MUST BE firmly
tightened to prevent unwanted movement of the wall plate [01] .
For concrete installations, follow STEP 2A
For wood stud installation, follow STEP 2B
WARNING:
