3-2

Hang [02] onto [01] and using a screwdriver, secure with the

preassembled screws [S1]

Remove the

preassembl

ed screws

[S2] and

save to use,

then raise

the safety

locks.

Press the safety locks

then fasten the

removed screws [S2].

0302

STEP 4 Hang TV with Brackets [03] onto the Front Support [02]

safety lock
