Perlick H80CIM SERIES - Page 19

PERLICK RESIDENTIAL UNDERCOUNTER CUBELET ICE MAKER PRODUCT MANUAL
perlick customer service (800)558-5592 | 19
INSTALLATION INSTRUCTIONS
5) Fasten the overlay panel to the door using the four
M4×25 pan head screws provided. Snug the screws,
but do not ghten (See Fig. 17).
6) Fasten the sheet metal bracket to the boom of the
door with the three T2 screws provided. Tighten the
screws to the door (See Fig. 18).
8) Replace the door gasket in its proper orientaon.
Reinsert the bushings into hinge (C1) and hinge (C2)
(the hinges aached to the door) (See Fig. 20).
Snug the screws,
but do not ghten.
Fig. 17
Sheet Metal Bracket
Screws
Overlay Panel
Door
Fig. 18
7) Tighten the four M4×25 pan head screws installed in
step 5 (See Fig. 19).
Fig. 19
Tighten the screws.
Bushing
Bushing
Gasket
Fig. 20
9) Aach the door to hinge (A), then connue to maintain
a hold on the door. Screw the hinge stop pin into hinge
(B) unl it is ght (See Fig. 21).
10) Insert the 2 canoe clips included in the accessory bag
into the holes on top of the door (See Fig. 22).
Hinge Stop Pin
Hinge (B)
Fig. 21
Canoe Clips
Fig. 22
