13
perlick.com
PERLICK RESIDENTIAL INSTALLATION MANUAL
5. Loosely attached the four corners of the overlay panel
with the door frame with #10 x 3/4” wood screws.
6. Make sure the overlay panel is aligned properly with
the door.
7. After alignment is satised, fasten down all screws
through the screw holes.
8. When re-installing the gasket, make sure the dart is
pressed inside the slot on the door frame. Start at the
four corners and rmly press your way inwards.
Do not overtighten wood overlay
attachment screws, as this may
damage the factory supplied door frame.
