Perlick SHALLOW-DEPTH Series Manual

43/3/2022
OPERATION 5: SCREWS REMOVAL
OPERATION 6: INSTALL MOUNTING BRACKET
1. WITH A PHILLIPS HEAD SCREWDRIVER, REMOVE SCREWS (2X) FROM UNIT SIDE BRACKETS.
2. KEEP COMPONENTS (SCREWS) ASIDE FOR RE-ASSEMBLY LATER.
SCREWS
SCREWS
BRACKET
1. ALIGN MOUNTING BRACKET TO HOLES (4X), 2 HOLES FROM WHERE OLD GRILL WAS SECURED TO (STEP 2),
AND THE OTHER TWO HOLES ARE THE ONES FROM PREVIOUS STEP (STEP 5).
2. UTILIZING A PHILLIPS HEAD SCREWDRIVER, SECURE BRACKET BY UTILIZING TWO SCREWS FROM STEP 5, AND
TWO SCREWS FROM STEP 6.
68 15/16”
23 7/8”
24 1/16”
