Activating the PM45-3G v1
Antenna Installation
Antennas can have their performance maximised using a ‘Ground Plane’, any metal mounting
surface will suffice. Please use the supplied ‘Ground Plane’ plate if you are not mounting this an-
tenna on a metal surface. A significant reduction in performance occurs if an antenna does not
have an adequate ground plane.
If signal strength is low, a high gain aerial may be required. The Permaconn Part N# is ‘ANTH3G’
Extension cables for the high gain aerial are available
Length in Meters Part N#
3 EXT3
5 EXT5
10 EXT10
NB: Do not exceed 10 meters.
Before powering up the PM45-3G v1 the device MUST be Activated.
The unit can be activated by: Control Room Administrators and Bureau Administrators with
activation rights.
NB: Control Rooms can restrict Bureaus from activating their own devices.
By doing so the Bureau may perform the activation procedure but must be approved
by the Control Room.
Activating the PM45-3G v1
1. Login to Atlas.
2. Select the ‘Fleet’ tab.
3. Click the ‘Activate’ button.
4. Input Permaconn serial number.
5. Fill in and follow the prompts.
NB: If the unit is powered up before activation, simply follow the Reset procedure set
out on page 5 of this manual.
RDCCO_2149_E_IN PM45-3G v1 March 2019 v1.4
