Permobil Permolock C3 - Manual release lever parts list

Permolock C3 Owner´s Manual Spare parts
35
ITEM QTY. ART. NO. DESCRIPTION
01 1 314036-99-0 MAN. CONTROL
02 1 HOLDER
03 1 HANDLE
04 1 612837-02-0 PLASTIC KNOB 4x13
05 1 SCREW
ISO 7380 M6x25 10.9 Fe/Zn 5 C1
06 1 BUSHING
07 1 WASHER
ISO 7089 6 200 HV Fe/Zn 5 C1
08 1 LOCKING NUT ISO 7040 M6 Fe/Zn 5 C1
09 1 WASHER ISO 7089 4 200 HV Fe/Zn 5 C1
10 1 SCREW ISO 4762 M4x5 8.8 Fe/Zn 5 C1
11 1 HOOK
12 3 COTTER
13 6 WASHER
5 Fe/Zn 5 C1 (SRB 5.3x12x1)
14 3 603083-99-0 LOCK LOOP
15 1 313997-00-0 COVER
16 1 314526-99-0 WIRE
17 1 612885-99-0 SPRING
DF 0.5x8x60
Spare parts
