Permobil VoltPro
Safety
RCM, Australian regulatory
compliance mark
For indoor use only
Figure 3. The charging connector pins.
The assignment of the charging connector pins must be as shown:
1. Positive
2. Negative
3. Inhibit (tied to negative)
21
