Permobil VoltPro
Operation
3.2 LED lights
Figure 4. LED lights showing the battery levels.
If the battery charger is correctly connected to a power outlet:
• LED will illuminate green.
• LEDs , , and will flash during the battery charger’s start-up
and then they will turn off until the batteries begin charging. The
number of times the LEDs flash indicate the charger setting. If the
LEDs flash once, the charger is set for Permobil AGM GEL
batteries. If the LEDs flash three times, the charger is set for MK
GEL batteries.
While the batteries are charging, the LEDs , , and will
illuminate as described below:
• When LED illuminates yellow, it means that the batteries are
empty and are being charged.
• When LEDs and illuminate yellow, it means that the
batteries are charged more than 50%.
• If LEDs and are flashing yellow, it means that there is an
error. See chapter 4
Troubleshooting
, page 27.
• When LED illuminates green in addition to LEDs and
that illuminate yellow, it means that the batteries are fully
charged.
24
