SetStationRunTimes



9. Toaccessthemenu,turnthemaindialtoStationRunTimes.

10. Pressthe or buttonstoselectprogram(A,BorC).Theprogramselectedwillbe

flashing.

11. Press toconfirm.Thecurrentstationisindicatedbyaflashingbox/blockorlineatthefar

rightofthedisplay.

12. Settherequiredruntimeforthisstationusing or .

13. Pressthe and buttonstomovetothenextstation.

14. Repeatsteps4and5forallstations.

15. PressOKtoconfirmandsavestationruntime.

16. Repeatsteps2to6forallprograms.

17. Stationruntimescanbesetfrom0–99minutes.



Note:



Ifthecontrollerhas2outputmodules,youcanprogramonly8stations

(2modules×4stations).

SetStationdelaytime



5. Toaccessthemenu,turnthemaindialtoStationDelayTime.

6. Theselectedmenufunctionwillstartflashing.Pressthe

and buttonstonavigate

fromstationruntimestostationdelaytime.

7. Settherequiredstationdelaytimeusing

and .

8. SavevaluesenteredbyleavingthemenubutpressOKbeforeleavingthemenu.

 Thestationdelaytimecanbesetfrom0‐99seconds.

Note:



Stationdelaytime:Thisfeaturedelaysthestartofthenextsequentialstation

 inaprogramafterthepreviousstationcompletes.



Pumpafter‐runtime:Toavoidpumplowpressuretripsthepumpmay

 continuerunningforacertainamountoftimeafterthelastsprinklercloses.
