Perrot Water Control+ SC - Module Setup for Sector Scout


TDP072d+e.doc Rev.07.07.2015 Seite‐Page49/64
PerrotREGNERBAUCALWGmbHIndustriestraße19‐29/D‐75382Althengstett/Germany
Telefon:0049‐7051‐162‐0/Fax:0049‐7051‐162–133
E‐mail:perrot@perrot.de/E‐mailKonstruktion:technik@perrot.de
 ConnectVP3withSectorScoutasperwiringschemeonpage7.
Pleasenotethatinthiscaseonly2stationspermodulecanbeconnected.
Changeentriesinthecontrollersoftwareasfollows:
ChannelA: wiredwithsolenoidand
ChannelB:wiredwithpositionsensor
 Pleaseproceedasfollows:
 Press and to select„Modulesetup“andpress toconfirm.


 Press
and toselectastationwhereaVP3withSectorScoutis
supposedtobeconnected.


 Use
tosettheselectedstationto„SCoutput“.

Warning
Ifboth,stationswithSectorScout(VP3SC)andstationswithvalves
only,areconnectedtothesamecontroller,allstationswithSector
Scouthavetobeconnectedinconsecutiveorderstartingfrom
module1.Thevalves(noSectorScout)canthenbeconnectedtothe
remainingmodulesregardlessoftheirorder.
 press toconfirmentry.
 Togetbacktothe„SectorScout“menu,press„previousmenu“.
