4.Installation
4.1Wallmounting
Chooseadrylocationprotectedfromdirectsunlightfortheinstallationofthecontroller
Removethefrontcover(seechapter5)andfixthebackcoverofthehousingtothewall
withthreescrews(includedinthepackage).
Pleasenotethatthecontrollermaytouchthewallonlyatthepointswithscrewholes.
Donotplugthecontrollerintothemainsuntilitismountedonthewall,allvalvesare
connectedandthefrontcoverisfixedbackinplace.
Mounting
hole
