3.Description

3.1 Performance
 3independentirrigationprograms(A,B,C),with4starttimeseach.
Expandableto5irrigationprograms.
 Stationruntime1–99min.
 Irrigationcalendarfor7days
 Manualstartofindividualstationsorprograms
 Startviakeyswitch
 Seasonaladjustmentfrom20–200%bywaterbudgetfunction

3.2 ElectricData
 Powersupply:230VAC,50Hz
 Outputvoltage24VAC
 Permanentoutputcurrent300mA
 Short‐termoutputcurrent450mA
 Short‐circuitprotectedoutputs
 Incaseofapowercut,thetimeandprogrammeddatawillbesavedbyabackup
battery.

3.4 Inputsandoutputs
 Stationconnections–variablefrom4to24stations
 2to12stationconnectionswhenusingtheSectorScoutfunction
 24VACmaster‐valveorapumprelay
 Potentialfreeopenercontact(rainsensor)
 Permanent24VAC

3.4 Indicatorsandfunctions

 LCdisplay70x40mm
 Displaystimeandstatusbar
 5multi‐functionkeys

3.5 Dimensionsandmiscellaneous
 Plastichousingdimensions:
length:350mm;width:270mm;height:110mm
 8fieldcableconnectionlugswithsafetysnagfeature
 Programmablestationdelaytimes(0‐99sec.)ensureproperpressure
conditions
whenvalvesopenandclose
 Pumpafter‐runtime(0‐15sec.)forpressurestabilization
