PAGE 21 OF 176
PHYSICAL SETUP: RF SETUP
4
Tighten screws clockwise in diagonal
order with a #1 Phillips Head screwdriver
until they stop (min. 4 in-lbs. of torque)
5
Pull on the RF module to verify that it is
attached securely. Ensure there are no gaps
in between the RF module and the MPU5
chassis.
1
2
3
4
To Next Page
