12 VB230/400-6/25/30LT
11. Commissioning
The device is to be put into operation in 3 steps:
1. Mounting
2. Connection and
3. Parameter setting
11.1 Mounting instructions
Caution: Danger to life through electric shock!
The following conditions are to be complied with in order to ensure a safe
and reliable operation of the VersiBrake…-LT:
1. The device series VersiBrake…-LT is to be used under overvoltage conditions
of the category III.
2. Make sure that pollution degree 2 or better, in accordance with IEC664, is
complied with.
3. The device is to be installed into a housing (min. degree of protection: IP54).
4. The device must be operated without being exposed to contamination by
water, oil, carbon deposits, dust, etc..
Warning:
Make sure that a minimum distance to adjoining devices is kept. Above and
underneath the housing a minimum distance of 50mm is to be kept.
11.2 Connection
The braking device is to be installed according to the attached connection diagram. For other
connections please consult PETER electronic GmbH & Co. KG.
Note: Further connection proposals for special circuit arrangements are available
via our homepage at www.peter-electronic.com.
Note: Prior to putting the motor brake into operation the wiring is to be checked.
To ensure reliable function is it necessary to comply with the interlocking conditions:
The interlocking contact of the braking device, terminal X5, X6, has to be looped into the control
circuit of the motor contactor, in order to prevent the motor contactor from pulling in during
braking.
