Bulb
Location
Type of
Bulb
Notes
Turn Signal/
Side Marker
Light/ Side
T
urn
Indicator
4157K
(SAE)
Dual
Filament
Bulb
Stop/ Tail
turn
1157 BULB
or LED
N/A
Backup 1156 BULB
or LED
N/A
Rear Tail
Light/ Turn
Signal
N/A LED
Roof
Markers
N/A LED
Hood
Markers
N/A LED
License
Light
N/A LED
Interior Map
Light
N/A LED
Interior
Dome Light
N/A LED
Bulb
Location
Type of
Bulb
Notes
Interior
Ambient
Light
N/A LED
Warning
lamp
module
#37 or 73
(T1 3/4
wedge
base)
N/A
Rear Suspension Fasteners
T
orque requirements apply to manufacturer
proprietary suspensions. All other
suspensions must refer and adhere to
original manufacturer's shop manual.
SIZE/TYPE
TORQUE
lb-ft N•m
M16 125-165 169.5-223.7
M20 all-
metal lock
nuts
315-350 427-475
SIZE/TYPE
TORQUE
lb-ft N•m
1/2 -in. nut 80-90 109-122
3/4 -in. nut 290-340 394-462
1-1/4 -in.
nut
1,380-1,630 1,877-2,217
Air Leaf Fastener Torque Values
Fastener
Fastener
Name
Torque lb-ft
(N•m)
1 NF x 8.5" Spring eye
bolt
225–550
(305–746)
0.75 NC x
2.25"
Alignment
cap screw
208–296
(282–401)
0.75 NF Spring eye
U-bolt
(rolled
threads)
50–100
(68–136)
0.75 NC x
5.0"
Spring eye
clamp bolt
165–210
(68–136)
MAINTENANCE - Specification Reference Charts
284 Y53-6113-1A1 (11/20)
5
