Trailer Air Supply
The red octagonal knob controls the air
supply to the trailer
.
Trailer, Axle (3rd Axle) Lift
Turn switch ON to lift 3rd Trailer Axle.
T
railer, Axle Lift Forward
Turn switch on to lift Forward Trailer Axle.
T
railer, Axle Lift Rear
Turn switch on to lift Rear Trailer Axle.
T
railer, Belly Dump
Turn switch on to open Trailer Belly Dump.
T
railer Dump Gate
Turn switch on to open Trailer Dump Gate.
T
railer, Belly Dump Gate Center
Turn switch on to open Trailer Center Belly
Dump Gate.
Trailer, Belly Dump Gate Front
Turn switch on to open Trailer Front Belly
Dump Gate.
T
railer, Belly Dump Gate Rear
Turn switch on to open Trailer Rear Belly
Dump Gate.
T
railer, Hotline
Turn switch on to supply electrical power to
trailer accessories.
CONTROLS - Dash Switches
Y53-6113-1A1 (11/20) 95
3
