Petzl FIXE - Page 2

2
P05SO P05W FIXE P055010B (080410)
FIXE
Specific information
Specific information General information
+ =
3 year guarantee - Made in France
1
Patented
2
3
4 bis
EN 12278
0082
90 g
individually tested
7
13 mm
Values
Working load limit
Valeur d’utilisation maxi
Maximale
Gebrauchslast
Valore d’utilizzo
massimo
Valor de utilización
máximo
5A.
5B.
2,5 kN 2,5 kN
5 kN
11,5 kN 11,5 kN
23 kN
Breaking load
Charge de rupture
Bruchlast
Carico di rottura
Carga de rotura
UIAA
2.
4.
5.
Tracability and Markings
3.
Inspection, points to verify
Compatibility
Field of application
1.
Nomenclature of parts
(EN) Pulley
(FR) Poulie
(DE) Seilrolle
(IT) Carrucola
(ES) Polea
Traceability:
datamatrix=
product reference
+ individual
number
Rope
diameter
c.
d.
00 000 A 0000
Year of
manufacture
Day of
manufacture
Control or name
of inspector
Incrementation
Individual number
e.
f.
g.
h.
i.
0082
APAVE SUD Europe BP 193,
13322 Marseille Cedex 16
N°0082
Body controlling the
manufacture of this PPE
Notified body that carried
out the CE type inspection
a. b.
F = 140 kg
F = 140 kg
F = 58 kg
F = 45 kg
F = P
F = 1,4 P
F = 2 P
F = 0,5 P
F = 0,58 P
F = 0,66 P
F = 0,33 P
F = 0,45 P
F = 0,57 P
90°
1,4 kN
6.
7. 8.
P = 100 kg
2 kN
120°
1 kN
Theoretical
force
6A. Simple pulley
system
with progress capture 6B. 2:1 hauling system 6C. 3:1 hauling system
with progress capture
Pulley system efficiency
Progress capture systems
Positioning and redirection
BASIC
BASIC
BASIC
BASIC
P = 100 kg P = 100 kg P = 100 kg P = 100 kg
P = 100 kg P = 100 kg
