Pfaff 1525

11 - 36
Adjustment
58.024
Fig. 11 - 32
1
2
3
58.024a
11.06.04 Knife height
Requirement
With the thread trimmer in its resting position the edges of thread catcher 3 and knife 1
must be flush (see arrow).
● Check knife height according to Requirement.
To adapt the height of knife 1, remove it (screws 2) and fit shims
(part No. 91-141 402-05) according to Requirement .
