6 PFAFF
Encoder adjustment
This work should only be carried out by a qualified technician.
1 Preliminary work
- Plug the 6 channel plug of the encoder into the motor control box.
- Turn master switch on.
2 Setting
The settings on the input panel are as follow:
press -LED off.
INPUT
appears in the display
press
SERVICE
press
PARAMETER 618
press - until display is at 700.
PARAMETER 700
press
Turn the hand wheel slowly in the direction of rotation (at least one turn!) until the point of the
needle is directly above the needle hole.
press
Switch to sewing mode.
press -LED on.
Operate pedal. The reference position (parameter 700) and the positions needle bottom dead
centre (b.d.c) (702) and needle top dead centre (t.d.c.) (703) have now been set.
Further parameter settings can be carried out in the main menu " 6 SERVICE ", sub function " 2
SEW. MOTOR " as described above (see also "Menu functions - overview" page 19).
