3
B
C
Place vertical in o position.
Coloque vertical en posición
de apagado.
Placez vertical en position
d’arrêt.
3A 3B
A
A
3
Install Valve and Cartridge - Instale la válvula y el cartucho - Installez le robinet et la cartouche
4
Install Flange and Handle - Instale la brida y el mango - Installez la bride et gérer
A
No Tools Required for This Step
No se necesitan herramientas para este paso
Aucun outil n’est nécessaire pour cette étape
4B4A
CB
Remove Sleeve and throw it
away after installation.
Retire la manga y tirarlo a la
basura después de la instalación.
Retirer manches et jetez-le après
l’installation.
PTFE plumber's tape
Cinta para plomería PTFE
Ruban PTFE de plombier
Adjustable Wrench
Llave ajustable
Clé à mollette
Pipe Wrench
Llave de tubo
Clé à Tube
Propane Torch
Antorcha de Propano
Torche de Propane
Tools needed will vary • herramientas necesarias variarán outils nécessaires varieront
