3)7*67$1'$5' 86$
6HWWLQJXSWKHPDFKLQH
BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB
BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB
________________________________________________________________________________________
Now, the following steps must be followed:
1. Turn main switch (1) to the "1" position.
If direction of rotation has to be changed, proceed as follows:
Lock pole reversing switch in position "O" by turning the arresting screw to the left or
the right side. The direction of rotation is now selected. If the switch is put to the left
side, it can be turned to "O" but cannot be turned to the right side. The figure printed
on the plate shows in which position the switch is locked.1HYHUWXQWKHSXPSGU\
:$51,1*
Do not take off the protection grille when preparing the machine or when machine is
operating.
If red lamp does not turn-off "change direction of rotation"; see check list.
2. Turn the green pressure switch "ON"
3. Press water flow button (1), and set approximate amount of water with needle
valve (2).
4. Couple the water hose from water flow meter to the mixing tube.
