The G 4 Standard is a continuous mixing pump for factory blended premixed dry mortar.
It can be filled by bags as well as by means of a delivery hood or an injection hood.
&RPSO\ZLWKWKHPDQXIDFWXUHUVPL[LQJLQVWUXFWLRQV
The machine consists of portable individual components whose compact dimensions and
low weight allow quick and easy transport.
Note the fllowing connections during operation:
1. Electrical panel – control box
2. Control box – pump motor
3. Control box - compressor
4. Compressor – air / water manifold
5. Water main supply – water manifold G 4 Standard
6. Mixing tube – Mortar pressure gauge
7. Mortar pressure gauge – mortar hose
8. Mortar hose – spray gun
9. Air / water manifold – air hose
10. Air hose – spray gun
