Page 18
© 2014 PG LifeLink, Inc. - All rights reserved
PG L
IFELINK Mark V Line Isolation Monitor Instruction Manual Rev. 2.0
which it occurred if possible, to aid in troubleshooting by phone or e-mail, or
in case the malfunction cannot be reliably replicated at the factory
System Errors 23 & 24 can be caused by faulty remote annunciator wiring.
Check the wiring by following the procedure in the above section covering
the LIM displaying “
Gn”. They can also be caused by poor quality incoming AC
power.
System Error Code Reference
Error Code Description
20 Problem in 1st level of user menu
21 Problem in 2nd level of user menu
22 Invalid switch command received from remote
23 Power line sync signal not within 50 — 60 Hz range
24 Line voltage outside normal range (approx. nominal -15% to +20%)
25 Unable to read internal Real Time Clock data
26 Analog channel command out of range
27 Factory cal procedure step is out of range
28 Stored hazard current range is invalid
29 Stored value for the auto-cal interval is bad
30 120V factory calibration value is out of range
31 240V factory calibration value is out of range
32 Cannot set Real Time Clock as commanded by LIM-CONNECT
TM
33 Calibration constant (unit sensitivity) outside acceptable range
34 Failure to write successfully to non-volatile event memory
Table 3 - Error Codes
