Phanteks EVOLV Series - 3.5 HDD Installation

15
REQ UIRE :
3 .5” H DD INST ALL A TIO N
B O T T OM C OMP ART MENT
T W O S T A C K - C ONF IGUR ATION SINGLE S T A C K - C O N F IGUR A TION
4x P h a n t e k s S tack a ble 3.5” H DD Br acke ts a r e inc luded.
Additional brackets are sold separately (PH-HDDKT_03).
The HDD bracket can also house
a 2.5” SSD instead of a 3.5” HDD.
4 x
Each HDD bracket can be stacked
together to offer more flexibility.
HDD
HDD INS T ALL A TION S T A CK / INSTALL R EMO V E
1. LIFT UP LATCH
2. PULL OUT
2
2
1
1
A
C
B
195mm PSU Clearance
250mm PSU Clearance
P OSITION A+C
P O S ITION B
3.5”HDD硬盘安装
HDD硬盘安装 支架堆叠安装 拆除
机箱标配4个可堆叠3.5“HDD支架
每个HDD支架可以堆叠在一起，以
便具有更大的灵活性。
HDD支架也可以安装
2.5”SSD
上拉闩锁
提升闩锁
两个堆叠配置
位置A+C
位置B
单堆叠配置
拉出
如需增加支架可单独购买（PH-HDDKT_03）
