散热器间距
18
R ADIA T OR CLEAR ANCE
MAX . R A DIATO R CLEA RANCE
140mm R adi ators: A:40 5mm B :146mm C:6 5mm
120mm R a diato rs: A:4 05mm B:1 2 6mm C :65mm*
T O P F R ONT
MAX . R ADIATOR CLEA RANCE :
A:465mm B:1 48mm C: 95m m
*If the motherboard and its components (e.g. memory)
are 50mm or lower there is no limit in Radiator thickness.
T O P
A
A
B
C
B
C
Installing a ll port in the top radiator bracket
and/or a drain port in the front of the case
makes water cooling maintenance much easier.
The port diameters are 20.5mm.
Phanteks Passthrough tting: PH-PTF_BK/CR_G1/4
Phanteks Ball-Valve tting: PH-BVA_BK/CR_G1/4
D R AIN PORT
FILL PORT
TNORF
*
如果主板及其组件（例如内存）为50mm或更低，则散热器厚度没有限制。
顶部
顶部
前面
最大散热器间距
最大散热器间距
前面
在顶部散热器支架和/或机箱前部的排水口安装注水口使水
冷维护更加容易。 端口直径为20.5mm。
追风者止水阀：
PH-PTF_BK/CR_G1/4
追风者球型塞：PH-BVA_BK/CR_G1/4
排水口
注水口
