VERTIC A L GPU SEC OND S Y STEM
REQ UIRE:
2 x
2 x
1.
INST ALL RISER C ABLE
2.
INSTALL V E RTIC A L G P U M O UNT WITH 2 X
S CRE W S
Riser Cable sold separately
(PH- CBRS_PR60)
3.
M O V E V E L C R O TIE
The GPU Mount has mounting positions.
Position A allows for better air cooling
and 3-slot GPU cards.
A
B
Depending on your needs, it’s not always necessary
to install a GPU for your second system when your ITX
motherboard is equipped with an onboard GPU.
1 x
1 x
1 x
R E M O V E :
1 x
第二系统垂直显卡
安装转接线
用2颗螺丝安装垂直显卡支架
移动魔术带
转接线需要另外选购
根据您的需要，当您的ITX主板配备集成显卡时，
可不为第二个系统安装显卡。
显卡安装座具有安装位置。 位置A更好
让空气冷却及安装3插槽显卡。
