Phantom Miro C110 - Page 11

Chapter 2: Connectors
5
Connectors
2
+16-28VDC
Ethernet
Trigger
AUX 1
AUX 2
SDI
Mini XLR connector connects to +16-28VDC Power
Supply.
Input: when a TTL pulse (rising / falling edge) is
detected, camera triggers.
BNC connector for HD video.
RJ45 connector connects GigE to a control unit
computer / laptop for camera control communication.
Input / Output (switchable via PCC):
• Default setting:
- F-Sync (input / output): Connect an external
source, including the F-Sync from a second
Phantom camera, to drive the camera’s frame rate.
Use in combination with Sync; External in
the External Sync menu.
• Available through drop-down box in PCC:
- Strobe (input): Signal goes low for the duration of
each frame’s exposure
- Event (input): When the Event signal is active,
frames are tagged with an Event marker (as
metadata). These events can be searched or
referenced during playback.
- Memgate (input): When Memgate signal is
active the camera stops recording into its internal
memory (frames are discarded).
Input / Output (switchable via PCC):
• Default setting:
- Strobe (Output): Signal goes low for the duration of
each frame’s exposure.
• Available through drop-down box in PCC:
- READY (output): When signal is high it indicates
that the camera is in capture mode. Using PCC,
signal can be set to go low at trigger or at the end
of recording.
A
B
C
D
E
F
