Chapter 2: Connectors | 5
CONNECTORS
A
B
C
D
E
F
G
K
I
M
P
H
L
O
J
N
Q
TRIGGER
TIME CODE IN
FSYNC /P
READY /P
STROBE /P
TC OUT /P
POWER SWITCH
1Gb ETHERNET
10Gb ETHERNET
PRIMARY DC INPUT
BACKUP DC POWER
CAPTURE PORT
REMOTE CONTROL PORT
RANGE DATA
GPS
HD-SDI 2 HD-SDI 1
TTL Pulse (Rising/Falling Edge), Switch Closure
IRIG-B In (Modulated/Unmodulated)
Programmable I/O (Default: F-Sync)
Programmable I/O (Default: Ready)
Programmable I/O (Default: Strobe)
Programmable I/O (Default: Time Code Out: (IRIG-B)
Off / Auto / On
CAT5 UTP (for control and data transfer)
RJ45 10GBase-T UTP (for control and data transfer)
20-28 Volts DC
20-28 Volts DC Backup
Ready, Strobe, A-Sync, Pre-trigger, NTSC/PAL, Video
RS-232 and Power (for Phantom Remote Control)
Used to stamp images with acquisition data (azimuth and elevation)
GPS input for GPS timing, longitude and latitude
The two HD-SDI ports can act as identical 4:2:2 HD-SDI ports with one set up to provide
an on-screen display to monitor the on-camera controls and camera operation
Assign and define Programmable I/O ports using PCC. Instructions
can be found in the Programmable I/O section of this manual.
