Chapter 3: Network Setup & Quick Start Guides | 11
3. Ensure the EDR (Extreme Dynamic Range) is set to zero (0).
4. Set ‘Post Trigger’ to zero (0) by:
• Moving the ‘T’ (Trigger Position) slider to the right, or
• Enter zero (0) into the ‘Last’ data entry field.
Click on the CSR button to perform a Current Session Reference. A CSR provides the
cleanest image at a given setting.
With color cameras, perform a White Balance by right-clicking an area of the image that is
neutral gray or white, as long as it is not 100 percent saturated.
FINE-TUNE SETTINGS
After CSR and White Balance are performed, adjust settings, aperture and/or lighting to
get a good exposure. A CSR must be performed after any camera settings are adjusted.
‘ARM’ CAMERA
Click the ‘Capture’ button to start recording to the camera’s internal RAM memory
(circular buffer).
TRIGGER
At the end of the action, click the ‘Trigger’ button at the bottom of the ‘Live’ panel, or
provide a switch closure or an external trigger signal (TTL pulse) via the Trigger connector.
PLAYBACK AND EDIT CINE
Click the ‘Play’ tab to ‘Scrub’ through the timeline or use the ‘Video Control’ buttons to
locate the first image to be saved.
Click the ‘Mark-in’ button.
Locate the last image of the Cine to be saved.
Click the ‘Mark-Out’ button.
REVIEW EDITED CINE
Select ‘Play, Speed & Options’ and enable (check) ‘Limit to Range.’
Under the ‘Video Control’ buttons, click the ‘Jump to Start’ button and review the
edited Cine.
