v2512 v2012 v1612 v1212
Max. Resolution
1280 x 800
Fps at Max. Res
25,700 22,600 16,600 12,600
Fps at Reduced
Resolution
1,000,000 at 256x32
with FAST option
(663,250 w/o)
1,000,000 at 128x32
with FAST option
(651,150 w/o)
1,000,000 at 128x16
with FAST option
(626,850 w/o)
820,500 at 128x16
with FAST option
(551,700 w/o)
Minimum Fps
100
CAR
128 x 16
Sensor Size
35.8 mm x 22.4 mm
Pixel Pitch
28 µm size, 12-bit depth
Min. Exposure
1 µs (standard)
265 ns
with FAST option
1 µs (standard)
290 ns
with FAST option
1 µs (standard)
500 ns
with FAST option
1 µs (standard)
500 ns
with FAST option
Straddle Time
375 ns 400 ns 425 ns 550 ns
Native ISO
(122232 SAT
Method)
Monochrome: 32,000D
Color: 6,400D
Adjustable
Exposure Index
(EI)
Mono: 32,000–160,000
Color: 6,400–32,000
Memory
72GB, 144GB, 288GB high-speed internal RAM
CineMag IV (1TB or 2TB), CineMag V (2TB or 8TB) non-volatile memory storage
Power
20–28VDC, 280 watt power supply included
Size & Weight
17 lbs, 8 oz. (8.1 Kg) (without lens)
Operational
Temperature
Operating Temperature: -10 to +50°C
10Gb Ethernet Operation: +5 to +50°C
CineMag V Run/Stop Operation: -10 to +40°C
Storage Temperature: -20 to +70°C
Humidity: 95% non-condensing
Shock Rating
Operational: 5.5 G, 11mSec sawtooth, 3 axes, 60 pulses total
Non-Operational: 30 G, 11mSec sawtooth, 3 axes, 60 pulses total
Ethernet
Standard Gb Ethernet and 10Gb Ethernet (standard)
Video
Two HD-SDI ports on camera; Analog video (NTSC or PAL),
available on Break-out-Box; Component viewfinder port
On-Camera
Controls (OCC)
Full OCC menu plus B-Ref, Tools, Playback and Trigger buttons
Programmable
I/O
4 ports; define parameters of F-Sync, Strobe, Event, Pre-trigger, Memgate,
Timecode-out, Ready, Aux, Auto-trigger
Special
Features
SYNC-to-Trigger, Image-Based Auto-Trigger, Burst Mode, PIV Exposure, Continuous
Recording, Multi-Cine with memory partitioning, Quiet Fans
SPECIFICATIONS
