Step 31
Prepare the ESC by soldering on your choice
of connectors. We recommend 4mm gold
bullet connectors. Ensure the polarity is
correct.
Step 32
Test fit the fan unit, noting the wires fit in
the moulded channel under the fin mount.
Apply epoxy sparingly as you may wish to
remove the fan unit at some point in the
future.
Step 33
Glue the fan unit in position making sure
none of the wires are trapped. Hold in
place until the epoxy cures.
Step 34
Prepare your rudder servo’s control horn as
shown. Centre the servo.
Step 35
Check the fit of your servo in the moulded
recess and trim the foam if necessary. Apply
a small quantity of epoxy to the servo.
