However, if you notice that your images contain cyan, magenta, or yel-
low lines in the direction parallel with the scan movement, then your
CCD sensor may be in need of cleaning. In this case, use the following
procedure:
1. With your system fully assembled and with the software running,
select Maintenance ➜ Cleaning Position from the Camera menu.
This will move the CCD to where it can be cleaned easily.
2. Spray the CCD sensor surface with a compressed air spray to remove
any abrasive dust.
3. Lightly moisten a clean piece of standard lens cleaning paper with
some isopropyl alcohol.
4. Rub the CCD sensor surface with the moistened lens cleaning paper.
Be careful not to get any alcohol anywhere else inside the camera
back. After the alcohol evaporates, inspect the CCD for dust. Repeat
if necessary.
5. Use one pump of Studiokit anti-static spray (included with your cam-
era back) to lightly moisten a new, clean piece of lens paper. Never
spray the fluid directly into your camera back.
6. Gently rub the CCD sensor surface with the moistened lens cleaning
paper. The purpose of this step is to apply a very light coating to pre-
vent static electricity from building up on the CCD surface. Do not
apply too much of the anti-static solution.
7. Always store your camera back with the dust cover slid all the way
down over the scan area, so that the CCD sensor and other internal
components are protected from dirt and damage.
Studiokit Digital Camera Back for Large Format Cameras – User's Guide
9
