Studiokit Digital Camera Back for Large Format Cameras – User's Guide
4
Fig.1 Back Panel of the Studiokit
CCD Sensor
Scan Area
SCSI
Connector
Scan
Direction
Protection
Legs
Dust Cover
Handle
(in open
position)
