SECTION 2: TECHNICAL SPECIFICATIONS
AC/DC KILOVOLTMETER
KVM300
KVM 300 DIVIDER
HIGH VOLTAGE AC INPUT:
300 KVAC maximum
HIGH VOLTAGE DC INPUT:
300 KVDC maximum
HIGH VOLTAGE PK INPUT:
300 KV peak max.
DIVIDER CAPACITANCE:
 67 pF
DIVIDER RESISTANCE:
1,200 M
DIVIDER RATIO:
10,000:1
INSTRUMENTATION: AC / BATTERY POWERED
POWER ADAPTOR:
INPUT: 100-240 Volts AC, 0.4 AMPS, 47-63 HZ
OUTPUT: +18 VDC, 0.8 AMP
INPUT JACK:
+18 VDC, 0.8 AMP
BATTERY PACK:
9.6 Volt Ni-MH 3200 mA hr
VOLTAGE MEASUREMENT:
Voltage is measured by means of Peak Responding, RMS or AVG
Circuitry. Display is 4 ½ Digit LED with adjustable backlighting
ACCURACY: 1% of Reading  3 counts from 10% -100% of Range
FUNCTION SELECTIONS:
1. Peak /  2 (Peak responding calibrated to RMS Value)
2. Peak (Peak responding calibrated to Peak Value)
3. RMS (True RMS)
4. AVG (True Average Value, not RMS equivalent)
5. Peak DC (Peak responding including ripple peak
6. Ripple Voltage (RMS value of a DC Ripple voltage)
FREQUENCY RESPONSE:
(SINUSOIDAL WAVEFORM)
Peak / 2, Peak, --Response: DC, 5-1000Hz
RMS, Ripple V --Response: 20 - 1000Hz
AVG --Response: DC, 20-1000Hz
SETTLING TIME:
Peak / 2, Peak --Up to 30 seconds
RMS, Ripple V --Up to 15 seconds
AVG --Up to 5 seconds
*Note: The lower the frequency the longer the settling time.
DIMENSIONS:
KVM 300
Controls 7” H x 12” W x 14” D 11 lbs.
HV 63” H x 26” W x 26” D 80 lbs.
