2. Stand the refrigerator upright, first
remove the screw cover 1 and loose the
screw 2 and unscrew the upper hinge
cover 3 which is at the top right corner
of the refrigerator, and use a putty knife
or thin-blade screwdriver to prize the
screw hole cover 4 which is at the top left
corner of the refrigerator.
3.Unscrew the flange screws 1 which
are used for fi xing the right upper hinge
part 2 . Lift the upper door and place it
on a padded surface to prevent it from
scratching.
Note: Please hold the upper door by
hand during step 3 to prevent door
dropping.
4. Remove the upper door and place it on
a smooth surface with its panel upwards.
Loose screws 2 , detach part 1 , then
install part 1 to the left side with screws
2
5. Loose screws used to fix the middle
hinge and remove middle hinge. Then
remove the lower door.
7
