6. Place the lower door on a smooth
surface with its panel upwards. Loose 2
screws detach part 1 .
Then install part 1 to corresponding
position on left side together with screws
2 .
7. Change screw hole covers on middle
cover plate from left to right (as shown in
fi gure below).
8. Place refrigerator fl atwise, remove part
3 and then loose screws 4 . Remove part
2 and part 1 .
9. Screw out lower hinge, change it to the
near hole site, and then screw up and
mount washer.
10. Just remount to the step 8, change
part 1 to left and part 2 to right and then
fi x them with screws 4 .
Finally install part 3 .
11. Move the lower door and adjust its
position to align lower hole site and upper
hinge axis. Turn the middle hinge by 180,
change the washer on the axis to the
upper side, adjust the middle hinge to the
appropriate position and then install it.
8
