Product Manual

AIRWAVE PROGRAMMING GUIDE

15.0 Linking/Unlinking an Airwave Switch or Photosensor to a Transceiver

TherearetwomethodstolinkanAirwaveSwitchand/orphotosensortoanAirwaveTransceiver.OneistousethepushbuttonsontheTransceivertoactivateLinkmodeandlinkadeviceandthe

secondistolinkbyusingthewirelessSwitchonly.

NOTE:ThemaximumnumberofwirelessdevicesthatcanbelinkedtoanyoneTransceiveris30.Thiscanbecomprisedof30Switchesandoccupancysensorsor1photosensorand29Switchesand

occupancy sensors.

15.1 Linking using push buttons on the Airwave Transceiver

15.1.1 ToLinkanAirwaveSwitch:

Step 1: Apply power to Transceiver.

Step 2: PresstheLinkbuttonontheTransceiverforonesecondandrelease(LinkLEDwillturnON).

Step 3: ClicktheAirwaveSwitch3times(ON3timesorOFF3times)rapidly(PowerLEDontheTransceiverwillremainONfor4seconds).

Step 4: Wait 4 seconds.

Step 5: PresstheLinkbuttonontheTransceiverforonesecondandrelease(LinkLEDwillturnoff).

Step 6: Repeatsteps3and4forasmanySwitchesthatneedtobelinkedtotheoneTransceiver.

15.1.2 ToLinkanAirwavePhotosensor:

Step 1: Apply power to Transceiver.

Step 2: PresstheLinkbuttonontheTransceiverforonesecondandrelease(LinkLEDwillturnON).

Step 3: PressthePhotosensorbuttononce(PowerLEDonTransceiverwillremainONfor4seconds).

Step 4: Wait 4 seconds.

Step 5: PresstheLinkbuttonontheTransceiverforonesecondandrelease(LinkLEDwillturnoff).

15.2 Linking Wirelessly

15.2.1 LinkingusinganAirwavewirelessSwitchtoaneworclearedTransceiver

Step 1: Apply power to Transceiver.

Step 2: ClicktheappropriateSwitch3timesON,then3timesoff,then3timesONrapidly.

NOTE:ThisprocessisusedforneworclearedTransceiversonly.TheSwitchwilllinktoallTransceiversthatarepoweredandwithinrangethatarenotcurrentlylinkedtoanyAirwave

Switches.Transceiversthatareunintentionallylinkedduringthisstepcanbeun-linkedremotelybyenteringthecongurationmodeandselectingClear(seeProgrammingGuide).

15.2.2 LinkinganadditionalAirwaveWirelessSwitchtoaTransceiver

AnexistinglinkedSwitchwillneedtobeusedtoenterthecongurationmodetolinkotherdevicesremotely(seeSection19.4forinstructions).

15.3 Unlinking Devices

Tounlinkadevice,repeattheLinkstepsforthatdevice.
