16.0 Linking/Unlinking an Occupancy Sensor to a Transceiver
16.1 Linking Wired 24Vdc Occupancy Sensors
Wired 24Vdc occupancy sensors can be wired directly to an Airwave Transceiver. The occupancy status can then be used by that Transceiver to control the connected light fixtures and can also
bewirelesslytransmittedtootherTransceiverswithinrange(seeOccupancyWiringDiagraminAppendixB).
Step 1: Connect24Vdc(red),Common(black),andOccupancyTrigger(yellow)wirestoappropriateoccupancysensorwires/contacts.
Step 2: Apply power to Transceiver.
Step 3: The first occupancy trigger will automatically set the Transceiver to occupancy mode.
Step 4: TolinkremoteTransceivers,pleaseseeSection19.8.
Step 5: Settheoccupancysensortimeronthewiredoccupancysensorperinstructionsonthesensor.TheTransceivertimerisfactorysettotrip30secondsafterthewiredoccupancy
  sensorhastimedout.TheTransceivertimerisnotuseradjustableforwiredsensors.
Afterlinkingiscomplete,theLEDwillblinkinapatterndependingonwhattypesofdevicesarelinkedtotheTransceiver(seeSection17).
16.2 Unlinking Wired 24Vdc Occupancy Sensors
Tounlinkawiredoccupancysensor,disconnecttheoccupancywires.ClearalldevicesusingtheinstructionsinSection19.7.Re-linkdesireddevices.
16.3 Linking Wireless Occupancy Sensors
ToLinkanAirwaveOccupancySensor:
Step 1: Apply power to Transceiver.
Step 2: PresstheLinkbuttonontheTransceiverforonesecondandrelease(LinkLEDwillturnON).
Step 3: PresstheOccupancySensorbuttononce(PowerLEDonTransceiverwillremainONfor4seconds).
Step 4: Wait 4 seconds.
Step 5: PresstheLinkbuttonontheTransceiverforonesecondandrelease(LinkLEDwillturnoff).
16.4 Unlinking Wireless Occupancy Sensors
TounlinkanAirwaveOccupancySensor,repeattheLinksteps.
