Philips Ledalite Airwave - 20.0 Configuration Mode Details

Product Manual
© Philips Ledalite 2011 Page 17
20.0 Configuration Mode – Detailed Instructions
ThissectionprovidesdetailedinstructionsoneachofthecongurationmodesdescribedinTableA–CongurationMenu.
NOTE:Therstiteminthemenu–BlinkCode0–isfactorypresetforxtureswithdimmingballastinstalled.However,Airwavedevicesalsosupportnon-dimmingxturesandsome
functionalitywillbehavedifferentlyifthelightingzoneisnon-dimming.Tosetthetransceiverfornon-dimmingfunctionalityfromwithincongurationmode:
Step 1: EntereditmodebypressingandholdingtheswitchONforatleast3seconds.
Step 2: Clickdown/offtoresetthetransceivertonon-dimmingfunctionality.
Step 3: PressandholdONforatleast3secondstoexiteditmode.
20.1 Blink Code 1: Timeout Settings Table
Thefactorydefaultforthissettingis15minutesforwirelessoccupancymodeandinnitelyONfornon-occupancymode.Wiredoccupancysensorshaveafactorytimeoutsettinginthe
Transceiverof30secondsthatcannotbeadjusted.
The factory presets should not require change. However, if the user requires a different setting:
Step 1: EntereditmodebypressingandholdingONuntillightsstopblinkcode1(approximately3seconds).
Step 2: ThelightswillnowdisplaytheTimeoutSettingBlinkCode.Clickon/upandoff/downtoselectthedesiredtimeoutsetting.
Step 3: PressandholdONforatleast3secondstoexiteditmode.
TimeoutSettingand
BlinkCode
OccupancyModeTimeDelay
(forWirelessOccupancySensorsOnly)
TimedSwitchModeDelay
(non-occupancymode)
0(lampofformin.dim) 30 seconds Innite
1 5 minutes 15 minutes
2 10 minutes 30 minutes
3 15 minutes 45 minutes
4 20 minutes 60 minutes
5 25 minutes 75 minutes
